THX AAA amp technology

Efficient DAC AK4493EQ*2

XMOS XUF208, 768K/32bit & native DSD decoding

QCC5124 【蓝牙芯片., high-definition encoding 支持部门

Full-series modules compatible, comes st和ard with THX amp AM3D

3.5mm single-ended + 4.4 balanced output

RGB light indicator

8. 多项 certifications









蓝牙 DSD- capable Amplifier



Q5s 类型-C

넳 넲



Efficient DAC AK4493EQ*2



XMOS XUF208,

768K/32bit & native DSD decoding





Full-series modules compatible, comes st和ard with THX amp AM3D





3.5mm single-ended

+ 4.4 balanced output



Fully stocked on inputs





QCC5124 【蓝牙芯片., high-definition encoding 支持部门



넳 넲

The Q5s （ C型版本） has acquired Hi-Res Audio certification, Hi-Res Audio Wireless certification, Qualcomm aptX certification 和 Sony LDAC certification.

Certified by multiple reputable institutions

넳 넲



Analog potentiometer volume knob for accurate volume adjustment





The implementation of the analog potentiometer volume knob effectively eliminates low-volume channel imbalance with traditional analog potentiometer volume knobs, thus allowing for much greater precision in adjusting the volume in tiny steps.



넳 넲

When connected to your computer, the Q5s （ C型版本） will automatically adjust its charging current 和 rate according to smart detection of the USB 端口's output capability. And when connected to a phone via USB, the Q5s will automatically know not to charge 和 draw power from it – so you can just use the Q5s free of any worries!
*

* When connected to an Android phone for decoding, the charging function needs to be set to 关 through the 卓苧控制 App.



Use it worry-free with intelligent adjustment

넳 넲

输出功率 ：>220mW (PO/32Ω)/>560mW (BAL/32Ω)

THD+N： <0.002% (1kHz/32Ω)

SNR  ：>117dB (A加权)

输出阻抗 ：1Ω

耳机输出：2.5+4.4(Bal)+3.5(PO)+LINE OUT

Variety of inputs：Micro USB/OPT/COAX/LINE IN

最高支持采样率：768kHz/32bit

DSD：DSD64/128/256

电池容量技术：3800mAh

电池续航能力：＞9 h

蓝牙编解码器 支持部门：AAC/SBC/aptXLL/aptX HD/LDAC

尺寸：about 124 mm× 64 mm× 16 mm

重量 ：about 198g

​​​​​​​





​​​​​​​​​​​​​​





具体规定

넳 넲





Chewing through formats with ease

Packing dual AK4493 chips



The extremely powerful flagship DAC 和 amplifier has once a增益 set a new bar in performance. The Q5s （ C型版本） employs a dual DAC design, with the left 和 right channels each equipped with the next generation AKM AK4493EQ DAC芯片一with its lower distortion, higher 信噪比, 和 greatly more refined mids 和 highs.



넳 넲

For ultimate convenience, you can simply enable the USB 音效 1.0 mode to experience decoding up to 96kHz/24 bit PCM without needing to install any drivers. (Press 和 hold the previous track button, then connect via USB to start USB 音效 1.0 mode)

No need to install drivers Fully compatible with both USB 音效 1.0 & 2.0

넳 넲

Discover more flexibility with just a few taps

With the 卓苧 Music app, after connecting the Q5s （ C型版本） via 蓝牙 you can adjust its channel balance, select the low-pass filter, control the RGB lights, 和 customize the power-saving shutdown timer.

넳 넲

USB A-C charging cable

Dual USB 类型-C cable

类型-C to Lightning cable

3.5mm line cable

Long binding strap*2

Short binding strap*2

同轴 patch cord

Optical adapter

T5 screwdriver

Non-slip mat

收纳 bag



A wealth of accessories for a premium experience

넳 넲

Omnipotent 类型-C 端口 eventually came true





Still holding on to the design language of a detachable amp module, the new version of Q5s is compatible with all 卓苧 AM-series modules. The st和ard AM3D balanced amp module included is equipped with the 类型-C 端口, along with the 3.5mm single-ended 和 4.4mm balanced headphone output.



넳 넲



THX AAA amp module





The AM3D is an independent amp module being certified by THX, meaning it has reliably cut the mustard of THX AAA technology. The two THX AAA-78 modules build a fully balanced amp architecture, achieving more superior audio performance as well as 输出功率, so to immerse users in a music world of high quality yet low distortion.

넳 넲

Massive improvement from upgraded clock management

In order to further improve sound quality, the Q5s （ C型版本） utilizes the XMOS XUF208 USB decoding chip paired with a precise clock matching management system, allowing for 支持部门 up to 768kHz/32 bit PCM 和 hardware-decoded native DSD – so you can be sure of excellent sound no matter what format your music is in.

넳 넲



Thanks to the Qualcomm QCC5124 【蓝牙芯片., the Q5s （ C型版本） is able to 支持部门 蓝牙 5.0, which keeps hi-res 蓝牙 formats like the LDAC 和 aptX HD, but with a new format added- aptX adaptive. It owns stable audio output streams so that it can ensure a free shuffle between low latency when playing games/watching videos, 和 high quality when enjoying music.



蓝牙 5.0

aptX adaptive added

넳 넲

A well-designed 电源 goes a long way towards achieving great sound. Alongside the numerous low-noise LDO regulators, the analog, digital, low-pass, 和 amplification sections of the Q5s are independently powered 和 isolated from each other – ensuring your music comes through as cleanly 和 purely as possible.

Audiophile-grade 电源

넳 넲

Feel the music through true high-fidelity sound

The dual AK4493EQ DACs work together with six carefully-implemented op amps to form a truly balanced audio design.4-channel analog volume control, Panasonic film capacitors

넳 넲



· The s和blasted all-aluminum alloy CNC chassis is worthy of a flagship

· The carefully-selected quality PU leather packing its back, gives you a feeling you will just grow positively attached to

· The long 和 short binding straps can freely bind it to other devices, making the connection more convenient.





Exquisite finish exudes quality luxury



넳 넲

The RGB lights are a clever way of indicating the audio format – the 6 different 彩色s quickly tell you which 蓝牙编解码器 is currently being played through the Q5s （ C型版本）
*When in USB decoding mode, the RGB lights indicate sampling rate.

Looking forward to turning on the lights

SBC： Blue

AAC：Cyan

LDAC：White

aptX adaptive：Green

aptX/aptX LL：Purple

aptX HD：Yellow





넳 넲

Intuitively know the details with just a glance

Each input mode is represented with a separate indicator light so you’ll know where you are playing from with just a glance. Long-press the input selection button on the side to view how much battery is left according to the status of 4 LEDs. Even with tiny details like these, we put 和 heart 和 soul into making the experience better for you.

넳 넲

In addition to USB 和 蓝牙 decoding, the Q5s （ C型版本） also 支持部门s SPDIF digital input 和 line-in analog input. The coaxial, optical, 和 analog line-in input are all h和led through a multifunction input 端口 that 支持部门s up to 192kHz/32 bit.

Fully stocked on inputs

넳 넲

The hardware 增益 和 bass boost control circuits ensures that the quality of your music doesn’t diminish while still allowing you to get your music to sound exactly the way you want it.

Find your rhythm with 增益 和 bass boost controls

넳 넲

USB decoding

＞9h



COAX

＞10h



AUX

＞25h



Bluethooth

＞9h

The massive built-in 3800mAh rechargeable polymer lithium-ion battery is sure to be able to get you through the day in most situations.

Plentiful power reserves for constant usage everyday
